Horizental Clean Bench, Standard Type

A laminar flow cabinet (clean bench) or tissue culture hood is a carefully enclosed bench designed to prevent contamination of semiconductor wafers, biological samples, or any particle sensitive materials. Air is drawn through a HEPA filter and blown in a very smooth, laminar flow towards the user. The cabinet is made of stainless steel with no gaps or joints where spores might collect.

Such hoods exist in both horizontal and vertical configurations, and there are many different types of cabinets with a variety of airflow patterns and acceptable uses.

Features:

1.Main HEPA filter efficiency ≥99.99%(@0.3μm)

2.Per-filter to prolong lifetime of main filter

3.SUS304 working area for easy cleaning

4.Adjustable fan unit & one-button velocity selection

5.Inter-locking system for illuminating light & UV lamp

6.Universal wheel & foot

ModelSW-CJ-1B-IISW-CJ-1BU-IISW-CJ-1C-IISW-CJ-1CU-II
Airflow TypeHorizontal AirflowHorizonta AirflowHorizonta AirflowHorizonta Airflow
Opertion side/Operator NumberSingle-side/Single-operatorSingle-side/Single-operatorSingle-side/Single-operatorSingle-side/Single-operator
Cleanliness   ClassISO Class 5,FED 209E Class 100ISO Class 5,FED 209E Class 100ISO Class 5,FED 209E   Class 100ISO Class 5,FED 209E Class 100
Filter Efficiency≥99.99%(@0.3um)≥99.99%(@0.3um)≥99.99%(@0.3um)≥99.99%(@0.3um)
Valocity(m/s)≥0.3m/s(Adjustable)≥0.3m/s(Adjustable)≥0.3m/s(Adjustable)≥0.3m/s(Adjustable)
Voltage/Frenquency(V/Hz)AC220V,50HZ,1ΦAC220V,50HZ,1ΦAC220V,50HZ,1ΦAC220V,50HZ,1Φ
Net Weight (kg)100100160160
Working Dimension(W*D*H)(mm)820*480*600820*480*6001680*480*6001680*480*600
External Dimension(W*D*H)(mm)900*700*1450900*700*14501760*700*14501760*700*1450


No.NameNote
1Electric SocketStandard
2SupporterStandard, integrated
3LightStandard, LED
4U.V.LightOptional
5Gas ValveOptional
6Water ValveOptional
