-40℃ Biomedical Freezer

Antech -40℃ Biomedical Freezer provides a reliable temperature performance with setting range -20℃ to -40℃. This products is designed to store vaccines, blood plasma, reagent and many other biological materials which is widely use in laboraotry, research institution, clinics, electronic and medical fields.

-40℃ Biomedical Freezer

Key Features

    Accurate temperature control to make inner temperature increment at 1 ℃
    High-tech integrated sensors to display and control temperature
    LCD+ Dual LED digital display for ease of observation
    Dirt-pickup resistant plastic coated shelf, adjustable height

Reliability

    Microprocessor controlled, adjustable temperature range: -20 ℃ to -40 ℃

    Digital temperature display with 1℃ resolution

    Removable outdoor double seals design for better temperature maintaining and energy saving

    Environment friendly refrigerant: CFC-Free and HCFC-Free.

Ergonomic Design

    Safety lock to prevent unauthorized access
    Caster design
    Remote alarm is standard configuration

    Chart recorder is optional
    Test port is optional

Safety

    Dual display to read multiple parameters: ambient temperature, power voltage, inner temperature etc.
    Built-in backup battery to display temperature and to operate audible and visual alarm system for up to 48 hours without AC power
    Three types of alarms: Buzzer, flashing light and remote alarm
    Multiple alarms: High/low temperature, power failure, sensor error, door ajar, low voltage in backup battery, hot condenser, high/low voltage alarm, high ambient temperature alarm


-40℃ Biomedical Freezer (Double Doors Type)

Ergonomic Design

    Double door design with independent locks reduces air leakage
    Door frame heating design prevents sealed strip from frosting
    Testing hole at back of freezer for convenient testing
    Independent drawers for convenient use and maximizes storage space
    Casters and feet is easy to move and fix
    Wide voltage design, normally work at 187-242V
    Environment friendly refrigerant: CFC-Free and HCFC-Free.



ModelMDF-40U90MDF-40U270MDF-25U450
Main specificationsTypeUnder-counterUprightUpright
Temperature range (℃) -20~-40 -20~-40 -20~-40
Cooling typeDirect   coolingDirect   coolingDirect   cooling
DefrostManual ManualManual
Climate typeNNN
Capacity (L)90270450
Intermal W*D*H (mm)500*485*532500*460*1235650*570*627
Extermal W*D*H (mm)700*669*854700*640*1792810*735*1960
Weight(KGs)5490144
RefrigerantR290R290R290
Number of compressor112
Control systemControllerMicroprocessorMicroprocessorMicroprocessor
DisplayLED   digital LED   digital LED   digital
Display accuracy 110.1
PowerPower   supply (V/Hz)220/50;   220/60; 120/60220/50;   220/60; 120/60220/50;   220/60; 120/60
Rated power (W)131;   170; 172255;   210; 179346;   375; 305
Rated current (A)1.3;   1.8; 4.22.8;   2.2; 4.24.5;   3.7; 5.3
DataUSB   portYesYesYes
RS485 portYesYesYes
Alarm functionsVisible/audible   alarm YesYesYes
High/low tempYesYesYes
Sensor failureYesYesYes
Door open YesYesYes
Low batteryYesYesYes
Power failureYesYesYes
Remote alarm contactYesYesYes
Other featureDoor   lock with keyYesYesYes
Adjustbale foot22N/A
Caster2N/A4
Test access portΦ25mm   x 1Φ25mm   x 1Φ25mm   x 2
Drawers3712
Door Qty112
MaterialExterior Pre-coated   steelPre-coated   SteelPre-coated   steel
Interior Pre-coated   aluminumPre-coated   aluminumPre-coated   aluminum
DoorSolid   doorSolid   doorSolid   door
InsulationPolyurethanePolyurethanePolyurethane
ShippingGross   weight (KGs)6098156
Packing WxDxH (mm)765x735x935760x720x1885895x820x2127
Volume (m³)0.531.031.56
