Combined Refrigerator & Freezer

Antech Combined refrigerator and freezer is 2°C~8°C refrigerator compartment up above and -40°C freezer compartment down below. The two compartments temperatures are controlled by two independent refrigerant systems. It have two compressors and control temperature more accurate which ensure the storage biological samples at reliable condition.

Cool specimens in two separate compartments with these combined refrigerator and freezer, offering a high-performance and space-saving alternative for cold lab storage.

Combined Refrigerator and Freezer Features

Intelligent Control System

High-precision microprocessor temperature control system with digital LED temperature display 0.1℃ accuracy. Temperature:Refrigerator: 2°C ~ 8°C, Freezer: -10°C ~ -40°C The digital display can show the freezer work condition and alarm code, it is easy to know the freezer satus 3 Channel sensors for cooling, display and amabinet temperature Security  Alarm System

Audibale and visible alarm system for safe storage High temperature alarm, Low temperature alarm, Sensor failure alarm, Door ajar alarm, Power failure alarm, Low battery alarm, High ambient alarm, USB failure alarm Optional for the remote alarm contact


Overview

Refrigeration System

Refrigerator compartment is forced-air cooling, freezer compartment is direct cooling

Two compressors control the refrigeration chamber and freezer chamber separately

Reliable compressor and fan, ensure fast cooling, energy-saving and long time running

Environment friendly refrigerant CFC-free and HFCF-free

Cabinet Construction

High thickness Non-CFC foamed insulation in refrigerator compartment freezer and compartment

Doorlock prevents unauthorized open

Low noise design creats a comfortable working environment

Superior engineered frame for maximum rigidity

Refrigerator compartment has adjustable shelves, freezer compartment has fixed shelves integrated with evaporator and

ABS drawers



ModelMRF-288AMRF-450A
Main specificationsTypeUprightUpright
Temperature setting  range (°C)Ref: 2~8; freezer:   -40~-10Ref: 2~8; freezer:   -40~-10
Climate typeNN
Capacity (L)Ref: 188; freezer:   100Ref: 315; freezer:   200
Net weight (kg)140186
Intermal W×D×H (mm)Ref: 600×510×710;   freezer: 500×460×505Ref: 750×610×740;   freezer: 650×560×565
Extermal W×D×H (mm)700×640×1845910×740×1972
Cooling typeRef: forced-air;   freezer: directRef: forced-air;   freezer: direct
DefrostRef: auto ;   freezer:manualRef: auto ;   freezer:manual
RefrigerantHydrocarbon gasHydrocarbon gas
Number of Compressor22
Control & display systemControllerMicroprocessorMicroprocessor
DisplayLED DigitalLED Digital
Temperature display accuracy 0.10.1
PowerPower   supply (V/Hz)220V/50Hz;   220V/60Hz; 120V/60Hz220V/50Hz;   220V/60Hz; 120V/60Hz
Rated power (W)330; 320; 375398; 425; 365
Rated current (A)2.5;   3.0; 5.53.6;   3.6; 6.5
DataUSB   portYesYes
RS485 portYesYes
Alarm functionsVisible/audible   alarm YesYes
High/Low temperatureYesYes
Hot condensor YesYes
Power failure YesYes
Sensor failureYesYes
High ambient temperatureYesYes
Door openYesYes
Low batteryYesYes
Remote alarm contactYesYes
AccessoriesDoor typeRef: forming door   with glass window; freezer: solid forming doorRef: forming door   with glass window; freezer: solid forming door
Shelves & drawersRef:   3 shelves + 1 drawer; freezer: 3 drawersRef:   3 shelves + 1 drawer; freezer: 6 drawers
Safety door lockYesYes
Test access portΦ25mm x 2Φ25mm x 2
Casters4 (2 with brake)4 (2 with brake)
MaterialExteriorCoated steelCoated steel
InteriorSUS304SUS304
InsulationPolyurethanePolyurethane
ShippingGross   weight (KGs)162215
Packing    W×D×H (mm)812×747×2004990×855×2140
Volume (m³)1.221.81
