Vertical Clean Bench, Desktop

A laminar flow cabinet (clean bench) or tissue culture hood is a carefully enclosed bench designed to prevent contamination of semiconductor wafers, biological samples, or any particle sensitive materials. Air is drawn through a HEPA filter and blown in a very smooth, laminar flow towards the user. The cabinet is made of stainless steel with no gaps or joints where spores might collect.

Such hoods exist in both horizontal and vertical configurations, and there are many different types of cabinets with a variety of airflow patterns and acceptable uses.

Features:

Space-saving desk-top type with compact design

SUS304 working area

Adjustable fan unit & one-button velocity selection

High efficiency & low power consumption

ModelVD-650VD-650-UVD-1320VD-1320-U
Airflow TypeVertical AirflowVertical AirflowVertical AirflowVertical Airflow
Opertion   side/Operator NumberSingle-side/Single-operatorSingle-side/Single-operatorSingle-side/Single-operatorSingle-side/Single-operator
Cleanliness   ClassISO Class 5,FED 209E Class 100ISO Class 5,FED 209E Class 100ISO Class 5,FED 209E   Class   100ISO Class 5,FED 209E Class 100
Filter Efficiency99.99%(@0.3um99.99%(@0.3um99.99%(@0.3um≥99.99%(@0.3um)
Valocity(m/s)0.3m/s(Adjustable)≥0.3m/s(Adjustable)0.3m/s(Adjustable)≥0.3m/s(Adjustable)
Voltage/Frenquency(V/Hz)AC220V,50HZ,1ΦAC220V,50HZ,1ΦAC220V,50HZ,1ΦAC220V,50HZ,1Φ
Net Weight kg)60609090
Working Dimension(W*D*H)(mm)615*495*500615*495*5001240*480*5501240*480*550
External   Dimension(W*D*H)(mm)650*535*835650*535*8351320*585*9501320*585*950




No.NameNote
1Electric SocketOptional
2U.V.LightOptional
3Gas ValveOptional
4Water ValveOptional
