Antech advanced CO2 backup system BS-1 is to ensure optimal security for critical samples stored in Ultra
Low Temperature Freezers. It controls injection of CO2 into freezer when freezer temperature rises above the preset temperature value.
It also reminds users to fill or replace their CO2 cylinders when pressure is low.
CO2 Back-up System
Advantages
· Compact design, small footprint, can be placed on freezer top;
· Temperature display, setting temperature adjustable by user;
· Unique low CO2 alarm, reminding user to change CO2 bottle in time;
· USA-made ASCO brand ultra-low temperature electromagnetic valve.
Safety & Protection
· Valve test button to check whether electromagnetic valve works normally;
· High/Low temperature alarm, low battery alarm, low CO2 alarm;
· Stop injection of CO2 when door opens, protecting user from being injured by liquid CO2 (need to be connected with ULT freezer door switch).
Reliability
· Stainless steel construction, rust-free, easy cleaning;
· Hose & injection tube with sponge cover for insulation
· Rechargeable battery for 36 hours working time.
| Model | BS-I | |
| Basic | Climate Class | N |
| Cooling Type | Direct Cooling | |
| Refrigerant | Liquid CO2 | |
| Performance | Cooling Performance (°C) | -70 |
| Temperature Range (°C) | -40~-70 | |
| Control | Controller | Thermostat |
| Display | LED | |
| Temperature Increment (°C) | 1 | |
| Electrical | Power Supply | AC 100~240V, 50/60Hz |
| Power (W) | 20 | |
| Electrical Current (A) | 0.25 | |
| Weight & Dimension | Net/Gross Weight | 11.2/13.6kg |
| 24.7/30lbs | ||
| Exterior Dimension (W*D*H) | 200*400*160 (mm) | |
| 7.8*15.7*6.3 (in) | ||
| Packing Dimension (W*D*H) | 370*530*330 (mm) | |
| 14.6*20.9*13 (in) | ||
| Function | High/Low Temperature Alarm | Yes |
| Low Liquid CO2 Alarm | Yes | |
| Low Battery Alarm | Yes | |
| Sensor Failure Alarm | Yes | |
| Main Power Failure Alarm | Yes | |
| Valve Open Indicator Light | Yes | |
| Main Power On Indicator Light | Yes | |
| Valve Test Button | Yes | |
| Accessories | *Hose (connecting backup system & CO2 cylinder) | 3 meter |
| Injection Tube (connecting backup system & freezer) | 2 meter |
*The specification of the joint connected to the CO2 cylinder is G 5/8〃
* Page parameters for reference only.
