CryoMonitor 2000TL

Liquid level & temperature monitoring system for liquid nitrogen containers. The CryoMonitor 2000TL provides accurate monitoring of liquid nitrogen level & temperature for liquid nitrogen containers storing cells, cord blood, embryo, semen and other biological samples.

CryoMonitor 2000TL records temperature and liquid level data, therefore, traceability is guaranteed. It also alarms users with sound & light when working status of container is out of normal range, to avoid irreparable loss of precious samples.

Furthermore, taking advantages of optional cloud service, data is transferred to and stored on cloud server, which can be visited from a PC or smart phone anywhere of the world. CryoMonitor 2000TL allows users to be completely rest assured with safety of samples.


1. Monitoring both temperature and liquid nitrogne level.

2. On-site alarm with sound & light.

3. Data stored in device & to be downloaded via USB port.

4. Wi-Fi connection & cloud data storage, worldwide data visit & alarm.

5. Backup battery for monitoring during power failure or movement.

Connection (Optional)

1. Wi-Fi connection to transfer data to cloud server.

2. Globle access on a PC, tablet or smartphone.


1. High/low temperature alarm

2. High/low liquid nitrogen level alarm

3. Power failure alarm

4. Low battery alarm


1. Wi-Fi connection status

2. USB connection status

3. Date & time

4. Sound alarm

5. Power connection status

6. Unit of temperature

7. Temperature display

8. Unit of liquid level

9. Liquid level display


CryoMonitor 2000TL offers the widest compatibility with liquid nitrogen dewars in the market, or already in

use at customer sites. Customized solution will be provided upon specific circumstances.

CryoMonitor 2000TL is easy to install, no need to drill a whole on plug or cap. Unlike plug type level meter,

there is no metal tube on plug, therefore, it is more convenient to work with.

ModelCryoMonitor   2000TL
Temperature   monitoring -200~+70°C
LN2 level   monitoring Yes
Temperature   sensorPT-100
LN2 level   sensorCapacitance
On-site alarmSound & light
Dimension   (Width x Height x Thickness)138 x 91 x 42mm
Net weight330g
Power supply100~240V, 50/60Hz, AC
Backup batteryBuilt-in lithium   battery, replaceable
Data storageYes
USB port for   data downloadYes
Romote alarm   contactYes
RS485 portYes
Internet   connectionWi-Fi
Cloud serviceOptional
Cloud alarmEmail, SMS
Plug groove   cutterOptional
