Horizental Clean Bench, Desktop Type

A laminar flow cabinet (clean bench) or tissue culture hood is a carefully enclosed bench designed to prevent contamination of semiconductor wafers, biological samples, or any particle sensitive materials. Air is drawn through a HEPA filter and blown in a very smooth, laminar flow towards the user. The cabinet is made of stainless steel with no gaps or joints where spores might collect.

Such hoods exist in both horizontal and vertical configurations, and there are many different types of cabinets with a variety of airflow patterns and acceptable uses.

Horizontal desktop LAF-Brochure

Main Features:

    Open uniform air exhaust with large area

    Portable, compact and flexible design

    Air volume adjustable system with high efficiency and low consumption

    Multi-grade electric safety protection

    Main HEPA filter efficiency ≥99.99%(@0.3μm)

    SUS304 working area for easy cleaning

    Adjustable fan unit & one-button velocity selection

    Inter-locking system for illuminating light & UV lamp

Applications of AIRTECH Various of Laminar Flow Cabinets / Clean Benchs:




Various Customized Clean Benchs:

ModelHD-650HD-650-UHD-1220HD-1220-U
Airflow TypeHorizontal AirflowHorizonta AirflowHorizonta AirflowHorizonta Airflow
Opertion side/Operator NumberSingle-side/Single-operatorSingle-side/Single-operatorSingle-side/Single-operatorSingle-side/Single-operator
Cleanliness   ClassISO Class 5,FED 209E Class 100ISO Class 5,FED 209E Class 100ISO Class 5,FED 209E   Class 100ISO Class 5,FED 209E Class 100
Filter Efficiency≥99.99%(@0.3um)≥99.99%(@0.3um)≥99.99%(@0.3um)≥99.99%(@0.3um)
Valocity(m/s)≥0.3m/s(Adjustable)≥0.3m/s(Adjustable)≥0.3m/s(Adjustable)≥0.3m/s(Adjustable)
Voltage/Frenquency(V/Hz)AC220V,50HZ,1ΦAC220V,50HZ,1ΦAC220V,50HZ,1ΦAC220V,50HZ,1Φ
Net Weight (kg)555500
Working Dimension(W*D*H)(mm)615*400*535615*400*5351120*490*5751120*490*575
External Dimension(W*D*H)(mm)650*980*625650*680*6251220*650*9201220*650*920


No.NameNote
1U.V.LightOptional
2Gas ValveOptional
3Water ValveOptional
